DeWalt DXVCS003 - Exploded View and Parts List

ENGLISH
4
EXPLODED VIEW / PARTS LIST
Dust separator1
2
3
4
5
6
7
1
1
2
2
2
2
1
1
PART DESCRIPTION QTY
Hose holder
Lid
Lid sealing strip
Lid latch
Dust tank
Handle
8
9
4
4
Wheel bracket
Caster bushing
10
Foot support
