DeWalt XR DCF403 - Package Contents; Markings on Tool; Description (Fig. A)

9
ENGLISH
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Nosepieces
2
Screw cap
3
Nose housing
4
Nose housing nut
5
Mandrel collector
6
Spare nosepiece holder
7
Exhaust vent
8
Main handle
9
Trigger switch
10
LED worklight
11
Battery pack
12
Battery release button
13
Spare jaws
Date Code Position (Fig.B)
The production date code
14
consists of a 4‑digit year followed
by a 2‑digit week and is extended by a 2‑digit factorycode.
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
g
Wear earprotection.
f
Wear eyeprotection.
n
Visible radiation. Do not stare intolight.
1 Set of spare jaws
1 Li‑Ion battery pack (C1, D1, E1, G1, H1, L1, M1, P1, Q1, S1, T1,
U1, X1, Y1, Z1 models)
2 Li‑Ion battery packs (C2, D2, E2, G2, H2, L2, M2, P2, Q2, S2,
T2, U2, X2, Y2, Z2 models)
3 Li‑Ion battery packs (C3, D3, E3, G3, H3, L3, M3, P3, Q3, S3,
T3, U3, X3, Y3, Z3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Package Contents
The package contains:
1 Riveter
4 Nosepieces (DCF403)
3 Nosepieces (DCF414)
Battery Type
The following tools operate on an 18‑volt battery pack:
DCF403, DCF414
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB183G, DCB184, DCB184B, DCB184G, DCB185,
DCB187, DCB189, DCBP034, DCBP034G, DCBP518, DCBP518G,
DCB546, DCB547, DCB547G, DCB548, DCB549. Refer to
Technical Data for moreinformation.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be recharged
beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:
L
Read instruction manual beforeuse.
p
Refer to Technical Data for chargingtime.
q
Do not probe with conductiveobjects.
r
Do not charge damaged batterypacks.
s
Do not expose towater.
t
Have defective cords replacedimmediately.
u
Charge only between 4˚C and 40˚C.
v
Only for indooruse.
x
Discard the battery pack with due care for
theenvironment.
y
Charge DeWALT battery packs only with designated
DeWALT chargers. Charging battery packs other than
the designated DeWALT batteries with a DeWALT
charger may make them burst or lead to other
dangeroussituations.
z
Do not incinerate the batterypack.
