DeWalt XR DCF809 User Manual

17
ENGLISH
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of DeWALT.
Karl Evans
Vice President Professional Power Tools EANZ GTS
DeWALT UK,
270 Bath Road, Slough
Berkshire SL1 4DX
England
04.08.2022
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.

DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which,
if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
General Power Tool Safety Warnings

WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this power
tool. Failure to follow all instructions listed below may result in
electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark areas
inviteaccidents.
b ) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust orfumes.
c ) Keep children and bystanders away while operating a
power tool. Distractions can cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electricshock.
b ) Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electricshock.
d ) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electricshock.
e ) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electricshock.
Batteries Chargers/Charge Times (Minutes)***
Cat # V
DC
Ah Weight (kg)
DCB104 DCB107
DCB112/
DCB1102
DCB113
DCB115/
DCB1104
DCB116 DCB117 DCB118 DCB132 DCB119
DCB546 18/54 6.0/2.0 1.08 60 270 170 140 90 80 40 60 90 X
DCB547 18/54 9.0/3.0 1.46 75* 420 270 220 135* 110* 60 75* 135* X
DCB548 18/54 12.0/4.0 1.46 120 540 350 300 180 150 80 120 180 X
DCB181 18 1.5 0.35 22 70 45 35 22 22 22 22 22 45
DCB182 18 4.0 0.61 60/40** 185 120 100 60 60/45** 60/40** 60/40** 60 120
DCB183/B/G 18 2.0 0.40 30 90 60 50 30 30 30 30 30 60
DCB184/B/G 18 5.0 0.62 75/50** 240 150 120 75 75/60** 75/50** 75/50** 75 150
DCB185 18 1.3 0.35 22 60 40 30 22 22 22 22 22 40
DCB187 18 3.0 0.54 45 140 90 70 45 45 45 45 45 90
DCB189 18 4.0 0.54 60 185 120 100 60 60 60 60 60 120
DCBP034 18 1.7 0.32 27 82 50 40 27 27 27 27 27 50
DCBP518 18 5.0 0.75 75 240 150 120 75 75 75 75 75 150
*Date code 201811475B or later
**Date code 201536 or later
***Battery charge times matrix provided for guidance only; charge times will vary depending on temperature and condition of batteries.
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536 or later
**Battery charge times matrix provided for guidance only; charge times will vary depending on temperature and condition of batteries.
***Battery charge times matrix provided for guidance only; charge times will vary depending on temperature and condition of batteries.

DeWalt XR DCF809 Specifications

General

Voltage	18V
No Load Speed	0-2800 RPM
Impacts Per Minute	0-3200 IPM
Power Source	Battery
Motor Type	Brushless
LED Light	Yes
Tool Holder	1/4 in
Battery Type	Li-Ion
Chuck Type	1/4" (6.35mm) Hex
Weight	2.2 lbs
Weight (without battery)	2.2 lbs
