Page #14 background imageLoading...
Page #14 background image
12
ENGLISH
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, depress the trigger lock button and
disconnect battery pack before making any
adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.
WARNING: Use only DeWALT battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. C)
DCS335: Move the on/off switch
1
to the OFF position before
inserting the batterypack.
NOTE: Make sure your battery pack
11
is fullycharged.
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
11
with the rails inside the
tool’shandle.
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
DCS335: Move the on/off switch
1
to the OFF position before
removing the batterypack.
1. Press the release button
12
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. C)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge button.
A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Blade Installation and Removal (Fig.D, J)
To Install a Blade
NOTE: This jig saw uses only T-shank jig sawblades.
NOTE: The DT2074 flush cutting blade is for use with D
eWALT
DCS334 and DCS335 jig sawsonly.
NOTE: When installing flush cutting blades (DT2074), the anti-
splinter insert (
20
, Fig. J) must be removed and the shoe must
to be in the 0° positive stopposition.
NOTE: The correct saw blade must be selected for the material
beingcut.
1. Hold open the blade release latch
4
as shown in FigureD.
2. Insert the T-shank blade into the clamp mechanism
13
while guiding the back of the blade into the groove of the
guide rollers
14
.
3. The T-shank should be completely inside the
clampmechanism.
4. Release the blade releaselatch.
To Remove a Blade
CAUTION: Do not touch used blades, they may be hot.
Personal injury mayresult.
1. Hold open the blade release latch
4
.
2. With a slight shake the blade will dropout.
3. Release the blade releaselatch.
Beveling the Shoe (Fig.E)
To Bevel the Shoe
1. Remove the dust extraction accessories if they are mounted
to the tool as the tool will not bevel if they are attached.
Refer to Dust Extractionsection.
2. Unlock the shoe by pulling the shoe bevel lever
8
to
theside.
3. Slide the shoe
7
forward to release it from the 0° positive
stopposition.
NOTE: The shoe can be beveled to the left or to the right
at a maximum of 45° in either direction. There are visible
detents at 15° and 30°.
4. Once the desired bevel angle is achieved, lock the shoe in
position:
a. For 0° and 45° bevel angles, slide the shoe back and lock
the shoe by moving the bevel lever back under the body
of the jig saw.
b. For all angles between 0° and 45°, lock with bevel
leveronly.
Cutting Action—Orbital or Straight (Fig.F)
This jig saw is equipped with four cutting actions, three orbital
and one straight. Orbital action has a more aggressive blade
motion and is designed for cutting in soft materials like wood
or plastic. Orbital action provides a faster cut, but with a less
smooth cut across the material. In orbital action, the blade
moves forward during the cutting stroke in addition to the up
and downmotion.
NOTE: Metal or hardwoods should never be cut in orbitalaction.
To adjust the cutting action, move the orbital action lever
6
between the four cutting positions: 0, 1, 2, and 3. Position 0 is
straight cutting. Positions 1, 2, and 3 are orbital cutting. The
aggressiveness of the cut increase as the lever is adjusted from
one to three, with three being the most aggressivecut.
