ENGLISH
Package Contents
The package contains:
1 Cut off tool
1 Diamond blade (X2 version only)
1 12.7mm wrench
1 Battery charger (X2 version only)
2 Li-Ion battery packs (X2 version only)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Risk of dustemission.
Higher risk of kickback! Do not use the upper quarter
of the wheel forcutting.
Date Code Position (Fig. A)
The date code
14
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Main handle
2
Trigger switch
3
Lock-off button
4
Battery door
5
12.7 mm wrench
6
LED light
7
Front handle
8
Guard
9
Arbor screw
10
Spindle lock button
11
Guard rotation lever
12
Shoe
13
Water valve
14
Date code
15
Water inlet
Intended Use
Your cut-off tool is designed for professional cutting
applications. Only use wet cut method when cutting concrete.
Dry cutting is possible when cuttingmetal.
DO NOT use in the presence of flammable liquids orgases.
Your cut-off tool is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
• DO NOT cut concrete without connecting the water
supplysystem.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. Make sure the
trigger switch is in the OFFposition. An accidental start-up
can causeinjury.

WARNING: Use only DeWALT battery packs andchargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)

WARNING: Do not work with unlatched battery door.
Prevent water entering into the batterycompartment.
NOTE: Make sure your battery pack
24
is fullycharged.
To Install the Battery Pack into the Tool
1. Unlatch and open the battery door
4
.
2. To install the battery pack
24
into the tool, align the
battery pack with the rails inside the tool and slide it in
until the battery pack is firmly seated. Ensure that it does
notdisengage.
3. Close the battery door and ensure it is closedsecurely.
To Remove the Battery Pack from the Tool
1. Unlatch and open the batterydoor.
2. Press the release button
16
and firmly pull the battery pack
out of thetool.
3. Insert it into the charger as described in Charging aBattery.
Do not leave the battery dooropen.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
