11
ENGLISH
objects from the belt hook. ONLY hang tool’s belt hook
from a workbelt.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing a belt hook, use only
the screw that is provided. Be sure to securely tighten thescrew.
A belt hook
14
can be be attached to either side of the tool
using only the screw
15
provided, to accommodate left- or
right-handed users. If the belt hook is not desired at all, it can be
removed from thetool.
To move the belt hook, remove the screw
15
that holds it in
place then reassemble on the opposite side. Be sure to securely
tighten thescrew.
Variable Speed Trigger Switch (Fig.E)
Lock-off Button and Trigger switch
Your saw is equipped with a lock-off button
2
.
To lock the trigger switch, press the lock-off button on the
left. Always lock the trigger switch
1
when carrying or storing
the tool to eliminate unintentionalstarting.
To unlock the trigger switch, press the lock-off button on the
right. Pull the trigger switch to turn the motor ON. Releasing the
trigger switch turns the motorOFF.

WARNING: This tool has no provision to lock the switch
in the ON position, and should never be locked ON by any
othermeans.
The variable speed trigger switch will give you added versatility.
The further the trigger is depressed the higher the speed of
thesaw.

CAUTION: Use of very slow speed is recommended only
for beginning a cut. Prolonged use at very slow speed may
damage yoursaw.
Worklight (Fig. A)
There is a worklight
9
located on the end of the tool near the
shoe. The worklight is activated when the trigger switch is
depressed. When the trigger is released, the worklight will stay
illuminated for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as a flashlight.
Blade Installation and Removal (Fig.C, F)
Different blade lengths are available. Use the appropriate blade
for the application. The blade should be longer than 90 mm and
should extend past the shoe and the thickness of the workpiece
during the cut. Do not use jigsaw blades with thistool.

WARNING: Cut hazard. Blade breakage may occur if the
blade does not extend past the shoe and the workpiece
during the cut. Increased risk of personal injury, as well as
damage to the shoe and workpiece mayresult.
To Install Blade into Saw
1. Twist open the blade clamp
3
to its full openposition.
2. Insert blade
11
fully into bladeclamp.
3. Release blade clamp. Gently tug on the blade to ensure blade
is clampedsecurely.
NOTE: The blade can be installed upside-down for flush cutting.
Refer to FigureF.
To Remove Blade from Saw

CAUTION: Burn hazard. Do not touch the blade
immediately after use. Contact with the blade may result
in personalinjury.
1. Twist open blade clamp
3
to its full openposition.
2. Removeblade
11
.
Hang Cleat (Fig. A, I)
The pivoting shoe
4
contains a hang cleat
13
that can be used
to hang the tool from North American 2x4 material and pipes.
To hang the tool, position the tool with the cleat over top the
material as shown in Fig. I.
NOTE: If using the hang cleat to hang the tool from pipe
or other rounded material make sure the foot of the tool
is supported by the wall or other material to keep the tool
fromswinging.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Proper Hand Position (Fig. D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle
8
,
or one hand on the main handle and one hand on the hand
grip
5
.
Cutting (Fig.D, F–H)

WARNING: Always use eye protection. All users and
bystanders must wear approved eyeprotection.

WARNING: Exercise extra caution when cutting towards
operator. Always hold saw firmly with both hands
whilecutting.
Before cutting any type of material, be sure it is firmly anchored
or clamped to prevent slipping. Place blade lightly against work
to be cut, switch on saw motor and allow it to obtain maximum
speed before applying pressure. Whenever possible, the saw
shoe must be held firmly against the material being cut. This
will prevent the saw from jumping or vibrating and minimise
blade breakage. Any cuts that put pressure on the blade such as
angle or scroll cuts increase potential for vibration, kickback, and
bladebreakage.
