DeWalt XR Li-Ion DCS565 User Manual

12
ENGLISH
Description (Fig.A, D)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch lock‑off button
2
Trigger switch
3
Battery pack
4
Depth adjustment lever
5
Shoe
6
Lower blade guard retracting lever
7
Lower blade guard
8
Blade clamping screw
9
Kerf indicator
10
Bevel adjustment lever
11
Worklight
12
Auxiliary handle
13
Battery release button
14
Hex key
15
Blade
16
Spindle
17
Rafter hook
Intended Use
Your DCS565 cordless circular saw has been designed for
professional wood sawingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These heavy‑duty circular saws are professional powertools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
Date Code Position (Fig.A)
The date code
24
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020XX XX
Year and week of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
g
Wear earprotection.
f
Wear eyeprotection.
n
Visible radiation. Do not stare intolight.
Package Contents
The package contains:
1 Circular saw
1 Circular saw blade
1 Hex key
1 Parallel fence
1 Dust extraction port
1 Charger (C, D, L, M, P, S, T, X, Y models)
1 Li‑Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2 Li‑Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3 Li‑Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The following tools operate on a 18 volt battery pack: DCS565
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB184, DCB184B, DCB185, DCB187, DCB189,
DCB546, DCB547, DCB548. Refer to Technical Data for
moreinformation.
s
Do not expose towater.
t
Have defective cords replacedimmediately
u
Charge only between 4˚C and 40˚C.
v
Only for indooruse.
x
Discard the battery pack with due care for
theenvironment.
y
Charge
DeWALT
battery packs only with designated
DeWALT
chargers. Charging battery packs other than
the designated
DeWALT
batteries with a
DeWALT
charger may make them burst or lead to other
dangeroussituations.
z
Do not incinerate the batterypack.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built‑in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).

DeWalt XR Li-Ion DCS565 Specifications

General

Battery Type	XR Li-Ion
Blade Diameter	165 mm
No Load Speed	4950 RPM
Max Cutting Depth at 90°	55 mm
Power Source	Cordless
Motor Type	Brushless
Voltage	18V
Weight	2.8 kg
