DeWalt XR Li-Ion TOOL CONNECT DCD992 Original Instructions

11
ENGLISH
Spotlight Mode
In factory default settings, mode 3is the spotlight mode. The
spotlight will run for 20minutes after the trigger switch is
released. Two minutes before the spotlight will shut off, it will
flash twice and then dim. To avoid the spotlight shutting off,
lightly tap the triggerswitch.

WARNING: While using the worklight in medium or
spotlight mode, do not stare at the light or place the
drill in a position which may cause anyone to stare
into the light. Serious eye injury couldresult.

CAUTION: When using the tool as a spotlight, be sure
it is secured on a stable surface where it will not cause a
tripping or fallinghazard.

CAUTION: Remove all accessories from the chuck before
using the drill as a spotlight. Personal injury or property
damage couldresult.
Low Battery Warning
When in spotlight mode and the battery is nearing complete
discharge, the spotlight will flash twice and then dim. After two
minutes, the battery will be completely discharged and the
drill will immediately shut down. At this point, replace with a
freshbattery.

WARNING: To reduce the risk of injury, always have a
back‑up battery or secondary lighting available if the
situation warrantsit.
Keyless Single Sleeve Chuck (Fig.H–J)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and remove the battery from the tool when
changingacces sories.

WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.
Your tool features a keyless chuck
6
with one rotating sleeve for
one‑handed operation of the chuck. To insert a drill bit or other
accessory, follow thesesteps.
1. Turn tool off and disconnect tool from powersource.
2. Grasp the black sleeve of the chuck
6
with one hand and
use the other hand to secure the tool. Rotate the sleeve
anticlockwise (as viewed from the front) far enough to
accept the desiredaccessory.
3. Insert the accessory about 19mm into the chuck and
tighten securely by rotating the chuck sleeve clockwise
with one hand while holding the tool with the other hand.
Continue to rotate the chuck sleeve until several ratchet
clicks are heard to ensure full grippingpower.
NOTE: Be sure to tighten chuck with one hand on
the chuck sleeve and one hand holding the tool for
maximumtightness.
To release the accessory, repeat steps 1and 2above.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
Torque Adjustment Collar/Electronic Clutch
(Fig.A, E–G)
Your tool has an electronic adjustable torque screwdriver
mechanism for driving and removing a wide array of fasteners.
Circling the torque adjustment collar
3
are numbers. These
numbers are used to set the clutch to deliver a torque range.
The higher the number on the collar, the higher the torque and
the larger the fastener which can be driven. To select any of the
numbers, rotate until the desired number aligns with thearrow.

WARNING: When the torque adjustment collar is in the
drill or hammerdrill positions, the drill will not clutch. The
drill may stall if overloaded, causing a suddentwist.
Bind‑Up Control®
The DCD992 and DCD997 are equipped with a Bind‑Up Control®
system. This feature senses the current through the motor
and reduces the motor torque to a manageable level before
ultimately shutting down. The Bind‑Up Control® system setting
is preset as disabled at the factory but can be customized using
the Tool Connect™ app. Refer to ModeSelector.
Three‑Speed Gearing (Fig.E–G)
The three‑speed feature of your tool allows you to shift gears
for greater versatility. To select speed 1(highest torque setting),
turn the tool off and permit it to stop. Slide the gear shifter
4
all the way forward. Speed 2(middle torque and speed setting)
is in the middle position. Speed 3(highest speed setting) is to
therear.
NOTE: Do not change gears when the tool is running. Always
allow the drill to come to a complete stop before changing
gears. If you have trouble changing gears, make sure that the
gear shifter is engaged in one of the three speedsettings.
If the speed shifter becomes stuck or is difficult to select the
desired gear, pull the trigger switch
1
to rotate the motor. Then
select thegear.
Gear speed settings are preset at the factory but can be
customized using the Tool Connect™ app. Refer to Mode
Selector table for factorypresets.
Worklight (Fig.A)

CAUTION: Do not stare into worklight. Serious eye
injury couldresult.
The worklight
5
located on the foot of the tool is activated
when the trigger switch is depressed. In the Home setting,
when the trigger is released, the worklight will stay illuminated
for up to 20seconds. If the trigger switch remains depressed,
the worklight will remain on. These settings can be customized
using the Tool Connect™ app. Refer to ModeSelector.
NOTE: The worklight is for lighting the immediate work surface
and are not intended to be used as aflashlight.
