Wireless eciever D003-002-02
Tested to Comply
With FCC Standards
FCC
Wireless Receiver
Tested to Comply
With FCC Standards
FCC
WHITE
GRAY
DewEze
COVER ALL SWITCH AND RELAY
CONNECTIONS WITH RUBBERIZED
UNDERCOATING OR DIELECTRIC GREASE
GRAY
Version II RF Control
Add-on Valve - 223017
Harness - 232041
(Included with
2 Bank Wiring
Harness)
SWITCH
(232005)
BRN
Note: The add-on valve (223017) used for 3-bank, New Generation (Gen II)
hydraulic systems is also required for 2-bank systems with 17 gpm pumps.
In the 2-bank, 17 gpm system, ports 3 and 4 are plugged with the caps
removed from 223017. The jumper wire connected to solenoid E must
be moved to solenoid C.
