MODEL IDENTIFICATION
MODEL 470 470W 475 477 478 480 482 485 487 578 582 587
WIDTH
7’ 7’ 8” 7’ 7’ 7’ 8” 7’ 8” 7’ 8” 7’ 8” 7’ 8” 8’ 8’ 8’
LENGTH
7’ 7’ 8’ 6” 9’ 4” 8’ 6” 9’ 2” 9’ 4” 10’6” 11’6” 8’ 6” 9’ 4” 11’6”
WEIGHT
1830 1860 1880 2000 1960 2020 2040 2220 2260 2060 2180 2400
*Add 100 lbs. for extendible arm option.
FLATBED SPECIFICATIONS
HYDRAULIC SYSTEM
Powered by engine driven pump or self-contained
battery-powered electric/hydraulic unit
SYSTEM PRESSURE
2450 psi
OIL RESERVOIR CAPACITY
10 Gallons
OIL FILTER
DewEze 720043, WIX 51551 (10 micron)
CYLINDER, LIFT
4.50” x 16.64”
CYLINDER, SQUEEZE
2.00” x 34.00” (400 Series)
2.00” x 39.25” (500 Series & all XRM)
CYLINDER, EXTENDIBLE*
2.00” x 20.0” (left side)
CYLINDER, EXTENDIBLE*
2.50” x 20.0” (right side)
*Cylinders used for extendible arm are optional.
BOLT TORQUE SPECIFICATIONS
(UNLESS SPECIFIED ELSEWHERE)
BOLT
DIAMETER
BOLT
TORQUE (ft-lb)
5/16” 19
3/8” 33
5/8” 160
1” 630
Specifications
Note:
Specifications are
for No. 5 bolts
with no lubricant.
