5 GB/IE
Front external siren (see Fig. D)
q
Speaker (external siren)
w
Cable (including socket connector) (external siren /
control unit)
Rear external siren (see Fig. E)
e
Top mounting point
e
a Bottom mounting point
r
Sabotage contact
t
Mounting screws (4 x)
Battery compartment external siren (see Fig. F)
y
Battery holder
Front motion detector (see Fig. G)
u
Infrared sensor
i
Cable (motion detector / control unit)
Rear motion detector (see Fig. H)
o
Housing rear
p
Preformed breakthrough points for attachment holes
Technical information
Control unit:
Operating voltage: 6 V
Stand-by current: approx. 0.1 mA
Alarm current: max. 120 mA
Power supply: 4 x batteries 1.5 V type LR6
(mignon / AA, alkaline) (not included)
Battery operating
life (stand-by): approx. 1 year
Battery warning: 4.5 V
Entry delay: 8 seconds
Exit delay: 30 seconds
Sabotage protection: against dismantling
Internal siren: approx. 100 dB(A) at a distance of 1m
Alarm time: approx. 60 seconds
LED:
Battery status warning: red
Exit delay: green
Speaker: pip sound key (to change the user
code)
melody (confirmation of own user
code)
Operation: 3 x 4 matrix keypad, user code, one
to ten digits
Operating temperature: approx. -10 °C to +39 °C
Dimensions: 6.5 x 9.0 x 4.0 cm
Housing material: ABS plastic
Motion detector:
Sensor: passive infrared
Detection range: approx. 90°
Range: approx. 6 m at 20 °C
Operating temperature: approx. -10 °C to +39 °C
Dimensions: 4.1 x 6.0 x 3.2 cm
Housing material: ABS plastic
Cable length: approx. 300 cm (including socket
connector)
Sabotage protection: against severing the cable
External siren:
Operating voltage: 6V
Current input: max. 120 mA
Power supply: 4 x battery 1.5 V type LR6 (mignon / AA,
alkaline) (not included)
Sabotage protection: against severing cable and disman-
tling
Piezo alarm: approx. 105 dB(A) at 1m distance
Alarm time: sabotage alarm: approx. 120 seconds
motion detection: approx. 60 seconds
Cable length: approx. 300 cm (including socket
connector)
Operating temperature: -10° to +39 °C
Dimensions: 6.5 x 9.0 x 4.0 cm
Housing material: ABS plastic
Safety advice
