[1] DC Usable Energy, test conditions: 90% DOD, 0.5C charge & discharge at 25°C. System usable energy may vary due to sys-
tem configuration parameters.
[2] The current is affected by temperature and SOC.
2.5
Product application solutions
The following illustration shows basic application of this battery.
It also includes following devices to have a complete running system.
- Generator or Utility
- PV modules
- Hybrid Inverters (Charge & Discharge)
Consult with your system integrator for other possible system architectures depending
on your requirements.
The picture is only an effect picture, please refer to the actual product, the final interpre-
tation right belongs to DEYE.
3
Parts List
Check the equipment before installation. Please make sure nothing is damaged in the pack-
age. You should have received the items in the following package.
To Next Page
