2.2 Identifying a CPU that Supports the
Multiplier Overclocking Function
Not all AMD CPUs support the multiplier overclocking function.
Please give special attention to L1 on the CPU. L1s four bridges
must be closed (short) in order for the frequency ratio selected on
SW1 to take effect. The figure below will help you identify the type
of CPU that would allow you to adjust its frequency ratio.
L1s four bridges closed (short).
L1s four bridges open.
Important:
We do not recommend that you adjust the CPU to a higher
frequency ratio because it may result to the CPUs or systems
instability and are not guaranteed to provide better system
performance. If you are unable to boot up the system with the
frequency ratio you selected, please power off the system and set
SW1 pins 1-5 to Off (Auto).
