5

Quick Setup Guide
Quick Setup
Guide
Chapter 1 - Quick Setup Guide
Table of Contents
1.1 System Board Layout..................................................................................................
1.2 Jumpers.....................................................................................................................................
1.3 Ports and Connectors................................................................................................
1.4 Award BIOS Setup Utility.......................................................................................
6
8
11
20
AM75-EC
(VIA
®
KM133)
AM75-TC
(VIA
®
KM133A)
Chipset
CPU
JP10
(CPU FSB select)
VT8365/686B
100MHz FSB
û
VT8365A/686B
100/133MHz FSB
ü
This users manual is for the AM75-EC and AM75-TC system
boards. The differences between these boards are shown below.
