62
!
Award BIOS Setup Utility
Onboard Legacy Audio (CA64-TC)
By default, this field is enabled allowing you to use the audio fea-
tures in DOS mode. The following fields are selectable only when
this field is set to Enabled.
Sound Blaster
This field is used to enable or disable the sound blaster.
SB I/O Base Address
This field is used to select the sound blasters I/O base address.
The options are 220H, 240H, 260H and 280H.
SB IRQ Select
This field is used to select the sound blasters IRQ. The options
are IRQ 5, IRQ 7, IRQ 9 and IRQ 10.
SB DMA Select
This field is used to select the sound blasters DMA. The options
are DMA 0, DMA 1, DMA 2 and DMA 3.
MPU-401
This field is used to enable or disable MPU-401.
MPU-401 I/O Address
This field is used to select MPU-401s I/O address. The options
are 330-333H, 300-303H, 310-313H and 320-323H.
Game Port (200-207H)
This field is used to enable or disable the onboard game port.
