6
Chapter 1 - Introduction
Specifications
SYSTEM Processor 8th Generation Intel
®
Core™/Pentium
®
/Celeron
®
LGA 1151 Socket Processors with
TDP up to 95W
Chipset CS630-H310: Intel
®
H310 Chipset
CS630-Q370: Intel
®
Q370 Chipset
Memory CS630-H310:
Two 288-pin DIMM up to 32GB, Dual Channel DDR4 2400/2666MHz
CS630-Q370:
Four 288-pin DIMM up to 64GB, Dual Channel DDR4 2400/2666MHz
BIOS AMI SPI 128Mbit
GRAPHICS Controller Intel
®
HD Gen 9 Graphics
Feature OpenGL 5.0, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x VGA VGA: resolution up to 1920x1200 @ 60Hz
1 x DVI-I (DVI-D signal) DVI-D: resolution up to 1920x1200 @ 60Hz
1 x DP++ DP++: resolution up to 4096x2160 @ 60Hz
Triple Displays VGA + DVI-I (DVI-D signal) + DP++
EXPANSION Interface CS630-H310:
1 x PCIe x16 (Gen 3)
1 x PCIe x4 (Gen 2)
5 x PCI
CS630-Q370:
1 x PCIe x16 (Gen 3)
1 x PCIe x4 (Gen 3)
5 x PCI
1 x mPCIe (supports mSATA)
1 x M.2 2260/2280 M key (PCIe Gen3 x 4 NVMe)
AUDIO
Audio Codec
Realtek ALC888
ETHERNET Controller CS630-H310:
1 x Intel
®
I211AT PCIe (10/100/1000Mbps)
1 x Intel
®
I219V LAN Phy (10/100/1000Mbps)
CS630-Q370:
1 x Intel
®
I211AT PCIe (10/100/1000Mbps)
1 x Intel
®
I219LM LAN Phy with iAMT12.0 (10/100/1000Mbps) (only Core i7/i5
supports iAMT)
REAR I/O Ethernet 2 x GbE (RJ-45)
USB 4 x USB 3.1 Gen1
2 x USB 2.0
Serial 1 x RS-232/422/485 (RS-232 with power) (DB-9)
PS/2 1 x PS/2 (mini-DIN-6)
REAR I/O Display 1 x VGA
1 x DVI-I (DVI-D signal)
1 x DP++
Audio 1 x Line-out
1 x Mic-in
1 x Line-in (opt., MOQ required)
INTERNAL I/O Serial 1 x RS-232/422/485 (RS-232 with power) (2.54mm pitch)
4 x RS-232 (2.54mm pitch)
USB CS630-H310:
4 x USB 2.0 (2.54mm pitch) or
2 x USB 2.0 (2.54mm pitch) + 1 x Vertical USB 2.0 (type A) (opt.)
CS630-Q370:
2 x USB 3.1 Gen 2 (2.00mm pitch)
4 x USB 2.0 (2.54mm pitch) or
2 x USB 2.0 (2.54mm pitch) + 1 x Vertical USB 2.0 (type A) (opt.)
Audio 1 x S/PDIF
1 x Front Audio Header
SATA CS630-H310:
4 x SATA 3.0 (up to 6Gb/s)
CS630-Q370:
5 x SATA 3.0 (up to 6Gb/s)
RAID 0/1/5/10
DIO 1 x 8-bit DIO
LPC 1 x LPC
SMBus 1 x SMBus
WATCHDOG
TIMER
Output &
Interval
System Reset, Programmable via Software from 1 to 255 Seconds
SECURITY TPM Infineon TPM2.0/1.2 (opt., MOQ required)
POWER Type ATX
Connector 8-pin ATX 12V power
24-pin ATX power
RTC Battery CR2032 Coin Cell
OS SUPPORT Windows 10 IoT Enterprise 64-bit
Linux: Ubuntu 18.04
ENVIRONMENT Temperature Operating: 0 to 60°C
Storage: -40 to 85°C
Humidity Operating: 5 to 90% RH
Storage: 5 to 90% RH
MECHANICAL Dimensions ATX Form Factor
305mm (12") x 244mm (9.6")
