Using J1939 output protocol makes possible DFM CAN operation as a part of
telematics bus together with DUT-E CAN fuel level sensors and other factory-built or
additional equipment (see figure 3 b). Tracking device with a single CAN interface port can
receive data from up to 8 DUT-E CAN sensors and up to 8 DFM CAN meters. This possibility
is especially useful while Vehicles with several engines (river boats, locomotives,
technological vehicles, diesel genset stations) are equipped.
Figure 4 — Example of Analytical Report generated in ORF 4 sofware,
based on the DFM CAN data
Use of DFM provides vehicle owners with the following:
 actual fuel consumption records;
 registration of machinery working time;
 normalizing of fuel consumption quotas;
 fuel theft detection and prevention;
 real-time monitoring and fuel consumption optimization;
 fuel consumption tests for engines.
