DFM general information and technical specifications / Exterior view and delivery set
DFM fuel flow meters. Operation manual. Version 6.4
© Technoton, 2017 13
1.2 Exterior view and delivery set
1 DFM fuel flow meter – 1 pc;
2 iButton key * – 1 pc;
3 fuse with holder (2 A) ** – 1 pc;
4 7.5m connection cable CABLE DFM 98.20.003 (7.5 m) *** – 1 pc;
5 Verification certificate – 1 pc;
6 Specification – 1 pc.
Figure 5 — DFM delivery set
* For DFM meters with built-in display.
** Not applicable for autonomous DFM fuel flow meters.
*** Only for DFM meters with pulse interface output.
