Assemble Side 1Assemble Side 1
Make sure the aluminum side panel faces the correct direction.
The protruding side of A3 should be facing outward.
A3
A2-1
To ensure functionality, do not over tighten C1
The protruding side of A3 should be facing outward.
A4-1
A1-1
C1
A3
