Assemble Side 2 Assemble Side 2
C3
C2
A2-2
A3
The protruding side of A3 should be facing outward.
A2-2
A3
The protruding side of A3 should be facing outward.
C3
C2
B3
Make sure the aluminum side panel faces the correct direction。
Make sure the aluminum side panel faces the correct direction。
