DHC BT797 User Manual

9
RECHARGE & RETEST
*Battery is discharged, the battery condition
cannot be determined until it is fully charged.
Recharge & retest the battery.
RECHARGE &
RETEST
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
BAD & REPLACE
*The battery will not hold a charge. It should be
replaced immediately.
BAD & REPLACE
VOL: xx.xx V
CCA: xxxx CCA/SAE
IR: xx.xx mΩ
BAD CELL & REPLACE
*The battery has at least one cell short circuit. It
should be replaced immediately.
BAD CELL &
REPLACE
VOL: xx.xx V
CCA:
xxxx
CCA/SAE
IR: xx.xx mΩ
LOAD ERROR
*The tested battery is bigger than
2000CCA/SAE or 200AH. Or the clamps are
not connected properly. Please fully charge the
battery and retest after excluding both previous
reasons. If reading is the same, the battery
shou
ld be replaced immediately.
LOAD ERROR
14.SOC & SOH Display: Press directional keys to see SOC & SOH:
GOOD & PASS
SOC:
xx.xx V
ˍˍˍˍˍˍˍˍˍˎ
90%
GOOD & PASS
SOH: xxxx CCA/SAE
ˍˍˍˍˍˍˍˍˍˎ
90%
15
.Press the ◄ ► key to select result printing:
YES or NO. Press «ENTER» to confirm your
choice.
PRINT RESULT?
YES/NO
16.Press «ENTER» return to MAIN MENU or remove the test clamps from the
battery posts after completion of testing batteries to end test.
9
