PARTS
B342079009W02
A
CUSHION-1
T610670
QTY: 1
LEG
T607420
QTY:4
CUSHION-2
T610680
QTY: 1
CUSHION CONNECTOR
T610690
QTY: 2
B C
D
HEX KEY
4mm
QTY: 1
BOLT
M6 X 15 mm
QTY: 8
1
2
HARDWARE PACK
T3191198-01
