DHP 2079009W - Step 2: Connect Cushions

6/11
B342079009W02
2
As shown in detail (1), slide the Cushion Connector (C) into the Cushions (A & B) and then fix all
the parts together by using the bolts 1, as shown in detail (2).
A
B
C
C
Detail 1
Detail 2
A
B
C
1
2
1
X8
