DHP 3135196 - Page 5

5 /16
PARTS
5
4
1
2
3
6
7
8
BOLT
1/4-20 x 55mm
T126580
QTY: 5
BOLT
5/16" x 20mm
T128080
QTY: 16
HARDWARE NOTE:
Please do not completely tighten any screws
until the entire assembly is complete.
Once assembly is complete, please be sure
tighten all hardware
HEX KEY
4mm
T290110
QTY: 1
BOLT
1/4-20 x 20mm
T125090
QTY: 22
HEX KEY
5mm
T290120
QTY: 1
SCREW
4.2 x 10mm
T115230
QTY: 20
NUT
1/4-20
T154200
QTY: 2
WRENCH
T129010
QTY: 1
B34313519600
