DHP 3137096 - Step 7: Attach Bed Frames to Mechanisms

DETAIL 1
DETAIL 3
DETAIL 2
DETAIL 4
After
assembling
After
assembling
14 /20
W
a
r
n
i
n
g
l
a
b
e
l
7
As shown in detail (1 & 2), attach the LOWER BED FRAMES-1 (J) to the MECHANISMS (L & R) with the BOLTS (3) and NUTS (7).
Attach the STOPPERS (T) and the HOOK (U) into place in the locations shown in details (3 & 4).
J
Hardware Required
3
7
x 8
x 8
V
V
V
J
J
3
7
7
R
R
U
U
UU
U
T
T
T
T
3
J
WARNING:
Use the frame assembled in step (5)
as seatrest, as shown.
PRECAUCIÓN:
Utilice el marco ensamblado en el
paso (5) como asiento, como se
muestra.
J
B34313709605
HOLE
HOLE
