DHP 3137096 - Hardware and Tools

6 /20
PARTS
B34313709605
HEX KEY-4mm
T290110
QTY: 1
WRENCH
T129010
QTY: 1
BOLT
1/4" x 2 3/8"
T126610
QTY: 10
BOLT
1/4" x 2"
T127340
QTY: 4
BOLT
1/4" x 1 3/8"
T127190
QTY: 8
BOLT
1/4" x 1 3/16"
T127150
QTY: 4
BOLT
5/16" x 3/4"
T128210
QTY: 16
BOLT
1/4" x 5/8"
T127160
QTY: 32
NUT
1/4"
T154290
QTY: 16
CURVED WASHER
D25.4 x d7.2 x 1
T208470
QTY: 8
SCREW
4.2 X 10 mm
T114650
QTY: 16
1
2
3
4
5
6
7
8
9
10
11
HARDWARE NOTE:
Please do not completely tighten any screws
until the entire assembly is complete. Once
assembly is complete, please be sure tighten
all hardware.
NOTA : Favor de no apretar completamente
los tornillos hasta que el ensamble haya sido
completado. Una vez que haya terminado el
ensamblado asegúrese de apretar bien todas
las partes.
