Lock the SPINDLES (I & J) into place by placing the SPINDLE BAR (H) on top of them on each end and fasten into place with
the SCREW (7) and WASHERS (6) as shown below.
6
B34545709600
Hardware Required
H
H
6
7
A
C
D
B
G
M
6
7
x2
x2
