DHP Maven Platform Bed 4124019 - Hardware Pack

6
Hardware Pack
B34412401900
Hardware Pack #: T4124019-00
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
6 7 8
4
5
3
2
1
1/4" X 3/4"
X 1
9
1/4" X 3/4"
X 13
1/4" X 1 3/16"
X 3
1/4" X 1 9/16"
X 6
6# X 1/2"
X 8
1/4"
X 4
4mm
X 1
1/4" X 1 9/16"
X 21
4# X 1 3/16"
X 20
