6. Settings Frequency Invertor
Please read the operating manual before setup the frequency invertor.
Par. No.
Name
Range
Unit
Setup
C00.33
LCP display option
0~4095
2
C00.40
HAND key option
0：Disabled；1：Enable
1（Default）
C00.41
OFF key option
0：Disabled；1：Enable；2：
Enabled reset only
1
C00.47
LCP Potentionmeter
Step
0：0.1；1：1；2：10
1（Default）
C01.20
Motor power
Motor dependant
kW
2.2 or 4.0
C01.22
Motor Voltage
50~1000
V
220/230
380/400/440/460
C01.23
Motor frequency
20~400
Hz
50 or 60
C01.24
Motor Current
Motor dependant
A
Motor dependant as
voltage
C01.25
Motor speed
100~9999
rpm
1000 or 1500
C01.39
Motor poles
2~100
P
6（2.2kW motor）
4（4.0kW motor）
C03.00
Reference Range
0: 0 ~ Max；
1：-Max~+Max
1
C03.03
Maximum reference
0.000~4999.00
50 (Default)
C03.15
Reference Source 1
0：no function；1：terminal
VI；2：terminal AI；8：pulse
input DI4；11：local bus；
21：LCP potentionmeter
21
C03.41
Motor speed up time
0.05~3600.00
s
5
C03.42
Motor speed down time
0.05~3600.00
s
8
C04.16
0~1000
%
1000（Default）
C04.17
0~1000
%
1000（Default）
C04.18
Current limit
0~300
%
280
C05.10
Terminal FOR
0: no operation；1: reset；6:
Stop inverse 9:Latched start；
37: Latched reversing
6
C05.12
Terminal DI1
9
C05.13
Terminal DI2
37
C06.81
LCP pot. Min. Refer.
-4999.00~4999.00
-50
C14.18
Delay time of Auto
Restart When power
again
0~3600
s
3600
C14.22
Operation mode
0：normal operation；2：
Initialization；3：Backing user
settings；4：Recover user
settings
Dependant
