DA40 NG
249
Obstacles
249
RWL
TOD
Obst. Dist.
„d“
„h“
„d“= (RWL + Obst.Dist.) - TOD
Gradient = („h“ / „d“) * 100
ROC =
Gradient x TAS
0.98
50 ft
50 ft assumed
Effective Obst. Dist.
Com
p
iled b
y
Peter Schmidleitner
DA40 NG
250
Vöslau RWY 31
950
600
830 m
1180
98 ft
„d“= (950 + 830) – 600 = 1180
Gradient = (30 / 1180) * 100 = 2,54 %
~ 200 fpm
At 1280 kg: ~ 380 fpm
„d“
