14
Com
p
iled b
y
Peter Schmidleitner
DA40 NG
27
LH front Ventilation
Air Inlets
Com
p
iled b
y
Peter Schmidleitner
DA40 NG
28
Air Inlets
Rear Ventilation
May be closed in cold weather with „Ventilation inlet baffle“
With ventilation inlet baffle installed: max OAT for Take-off:
15°C
