Diamond DA40 NG - Fuel System; Fuel Tank Capacities

73
Com
p
iled b
y
Peter Schmidleitner
DA40 NG
Fuel system
 For exact indication the airplane
must stand on horizontal ground
with wings level
 Therefore:
 „Fuel indicator II“ is available for pitch
angle measurement
 Place it on top of fuselage in front of
vertical tail
 Read pitch angle and use table to
determine exact fuel quantity
145
Com
p
iled b
y
Peter Schmidleitner
DA40 NG
Fuel system
Fuel Qantity Indicator II
Qantity scale
Level scale
146
