_______________________________ DOUGH MIXER IRIS _______________________________
24
TAV. 01 Dough mixer IRIS 30-40 rev.00
45 410192010 410192010 THREADED BAR
46 482550003 482550003 WHEEL 6 LOBE PASSING HOLE
47 423240032 423240032 TRAPEZOIDAL BELT
48 321400380 321400380 BOWL TRANSMISSION DRIVEN PULLEY
49 321400400 321400400 SPIRAL TRANSMISSION DRIVEN PULLEY
50 423240017 423240017 TRAPEZOIDAL BELT
51 321400490 321400490 MIXER MOTOR PULLEY
52 467341200 467341200 MOTOR 2°V IRIS 30-40 IN 220/50
52 467341400 467341400 MOTOR 2°V IRIS 30-40 IN 400/50
52 467341300 467341300 MOTOR 2°V IRIS 30-40 IN 220/60
52 467341500 467341500 MOTOR 2°V IRIS 30-40 IN 400/60
53 321400500 321400500 BOWL TRANSMISSION MOTIVE PULLEY
54 315400070 315400070 PIN MOTOR SUPPORT CLUTCH
55 303900071 303900071 BOWL MOTOR MOBILE SUPPORT
56 410192010 410192010 THREADED BAR
COLOURS
* WHEN ORDERING PLEASE SPECIFY MIXER COLOUR
WHEN ORDERING PARTS PLEASE SPECIFY REGISTRATION NUMBER
CODE COLOUR
BASE CODE -01 WHITE
BASE CODE -02 CREAM
BASE CODE -03 METAL GREY
BASE CODE -04 LIGHT BLUE
BASE CODE -05 YELLOW
