_______________________________ DOUGH MIXER IRIS _______________________________
27
TAV. 02 Dough mixer IRIS 60-300 - Structure and panels Rev.001 01-06-2012
Pos. Mod. 60 Mod. 80 Mod. 100 130 Mod. Mod. 16 Mod. 200 Mod. 250 Mod. 300
Descrizione
1*
306200520 306200120 306200120 306200210 306200140 306200140 306200140 306200140
* PLASTIC MIXER LID
2
410347010 410347010 410347010 410347010 410347010 410347010 410347010 410347010
BLIND INOX NUT
3
411015010 411015010 411015010 411015010 411015010 411015010 411015010 411015010
PLANE INOX WASHER
4
362600020 362600020 362600020 362600020 362600020 362600020 362600020 362600020
MIXER CONTROL PANEL COVER
5
463200007 463200007 463200007 463200007 463200007 463200007 463200007 463200007
ELETRIC TIMER 1
ST
SPEED 48x48
6*
464102001 464102001 464102001 464102001 464102001 464102001 464102001 463402001
COMP. SWITCH SIEMENS INV. BOWL MIXER IRIS
7*
464102002 464102002 464102002 464102002 464102002 464102002 464102002 463402002
* COMPLETE GREEN BUTTON SIEMENS START MIXER IRIS
8*
464102003 464102003 464102003 464102003 464102003 464102003 464102003 463402003
* COMPLETE BLACK BU
TTON TELEMECANIQUE BOWL ROTATION
9*
464102004 464102004 464102004 464102004 464102004 464102004 464102004 463402004
* COMPL. BLACK SWITCH SIEMENS LOW/HIGH SPEED IRIS
10
463200007 463200007 463200007 463200007 463200007 463200007 463200007 463200007
ELETRIC TIMER 2
ST
SPEED 48x48
11*
460201002 460201002 460201002 460201002 460201002 460201002 460201002 460201002
* SCREEN-PRINTED PANEL FOR MIXER IRIS
12*
464102005 464102005 464102005 464102005 464102005 464102005 464102005 463402005
* COMPLETE RED BUTTON SIEMENS EMERG. IRIS
13*
553120020 553120020 553120020 553120020 553120020 553120020 553120020 553120020
* CONTROL PANEL MIXER 60-300 IRIS DIGITAL ELETTROMEC. SIEMENS
13*
553120010 553120010 553120010 553120010 553120010 553120010 553120010 553120010
* CONTROL PANEL MIXER 60-
300 IRIS ELETTROMEC. TELEMECANIQUE
14
356300040 356300040 356300040 356300040 356300040 356300040 356300040 356300040
THREADED BAR
15
410320010 410320010 410320010 410320010 410320010 410320010 410320010 410320010
HEXAGONAL NUT
16*
308600290 308600290 308600290 308600290 308600290 308600290 308600290 308600290
* BACK MIXER AIRING PANEL
17
482520002 482520002 482520002 482520002 482520002 482520002 482520002 482520002
LOCK WITH KEY WITH FINS
18
462660007 462660007 462660007 462660007 462660007 462660007 462660007 462660007
ON-OFF MAIN ROTATING SWITCH
19*
307600011 307600010 307600010 307600040 307600020 307600020 307600020 307600020
* MIXER CONTROL PANEL DOOR
20
483010001 483010001 483010001 483010001 483010001 483010001 483010001 483010001
PLASTIC FOOT ARTICULATED STEM Fe
21
429320002 429320002 429320002 429320002 429320002 429320002 429320002 429320002
WHEEL WITH TURNING SUPPORT HEAVY CAST IRON + POLES
22
429330001 429330001 429330001 429330001 429330001 429330001 429330001 429330001
WHEEL WITH FIXED SUPPORT D100 SUPPORT PE
23*
301100270 301100070 301100070 301100190 301100100 301100100 301100100 301100510
* MIXER BODY IRIS
24*
308600280 308600280 308600280 308600280 308600280 308600280 308600280 308600280
* LOWER INSPECTION HATCH. IRIS
* WHEN ORDERING PLEASE SPECIFY MIXER COLOUR WHEN ORDERING PARTS PLEASE SPECIFY REGISTRATION NUMBER
CODE COLOUR CODE COLOUR
BASE CODE -01 WHITE BASE CODE -04 BASE CODE -04
BASE CODE -02 PANNA BASE CODE -05 YELLOW
BASE CODE -03 METAL GREY
