Diamond IRIS - Page 30

_______________________________ DOUGH MIXER IRIS _______________________________
29
TAV. 03 Dough mixer IRIS 60-300 - Upper drive unit Rev.001 01-06-2012
Pos.
Mod. 60 Mod. 80 Mod. 100 130 Mod. Mod. 160 Mod. 200 Mod. 250 Mod. 300 Descrizione
1
429005002 429005002 429005002 429000001 429000001 429000001 429000001 429000001 CONE BUSH / KEYER
2
423240074 423240085 423240085 423240093 423240096 423240096 423240096 423240096 TRAPEZODAL BELT
3
423010525* 423010525* 423010525* 321400424* 321400424* 321400424* 321400424* 321400424 *
SPIRAL DRIVEN PULLEY MIXER IRIS
4
420812008 420812011 420812011 421005007 421005007 421005007 421005007 421005007 UPPER BEARING MIXER SPIRAL IRIS
5
303800310 303800220 303800220 303800220 303800220 303800220 303800220 303800220 SPIRAL BEARING SUPPORT
6
421025003 421005004 421005004 421005007 421005007 421005007 421005007 421005007 BEARING
7
422600005 422600007 422600007 422600010 422600010 422600010 422600010 422600010 OIL BLOCK
8
315000300 315000140 315000140 315000120 315000120 315000120 315000120 315000120 MIXER SPIRAL HOLDER SHAFT
9
369000020 369000020 369000020 369000030 369000030 369000030 369000030 369000030
PLASTIC CUP
10
372700080 372700010 372700010 372700060 372700020 372700020 372700030 372700090
MIXER SPIRAL- IRIS
11
467253400 * 467263401 * 467263400 * 467263402 * 467273400 * 467273400 * 467273401 * 467273402
* SPIRAL MOTOR
12
317500050-53 317500010-53 317500010-53 317500010-53 317500020-53 317500020-53 317500020-53 317500020-53
SPIRAL MOTOR SLIDE
13
321400261 321400260 321400260 321400171 321400170 321400170 321400170 321400170
SPIRAL MOTIVE PULLEY
14
346600020 346600020 346600020 346600020 346600020 346600020 346600020 346600020
PLAIN WASHER
15
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - -
16
303900131-53 303900131-53 303900131-53 303900261 303900261 303900261 303900261 303900261
SPIRAL TRANSMISSION SUPPORT MIXER
17
315000160 315000160 315000160 315000250 315000250 315000250 315000250 315000250
ALBERO PULEGGIA RINVIO
18
420812009 420812009 420812009 420812020 420812020 420812020 420812020 420812020
BEARING
19
423240014 * 423240021 * 423240021 * 423240021 * 423240031 * 423240031 * 423240031 * 423240031
* TRAPEZODAL BELT
20
321400250 * 321400250 * 321400250 * 321400430 * 321400430 * 321400430 * 321400430 * 321400430
*PULEGGIA DOPPIA
21
420812009 420812009 420812009 420812020 420812020 420812020 420812020 420812020
BEARING
22
351400080 351400080 351400080 351400080 351400080 351400080 351400080 351400080
DISTANZIALE
23
Vedi pos. 16 Vedi pos. 16 Vedi pos. 16 Vedi pos. 16 Vedi pos. 16 Vedi pos. 16 Vedi pos. 16 Vedi pos. 16
SUPPORTO RINVIO SPIRALE
* WHEN ORDERING PLEASE SPECIFY MIXER COLOUR
WHEN ORDERING PARTS PLEASE SPECIFY REGISTRATION NUMBER
