_______________________________ DOUGH MIXER IRIS _______________________________
31
TAV. 04 Dough mixer IRIS 60-300 - Bowl and protections Rev.001 01-06-2012
Pos.
Mod. 60 Mod. 80 Mod. 100 130 Mod. Mod. 160 Mod. 200 Mod. 250 Mod. 300 Descrizione
1
362500380 362500100 362500110 362500070 362500050 362500060 362500210 362500320
METAL BOWL PROTECTION IRIS
1
362400810 362400090 362400090 362400180 362400110 362400110 362400960 362400950
* PLASTIC PROTECTION IRIS
2
464805001 464805001 464805001 464805001 464805001 464805001 464805001 464805001
BOWL PROTECTION LIMIT SWITCH
3
332800010 332800010 332800010 332800010 332800010 332800010 332800010 332800010
GRID LIMIT SWITCH STARTER RANGE
4 *
490202015 490202015 490202015 490202015 490202015 490202015 490202015 490202015
DRAWN ROD D. 15
5
334000051 334000051 334000051 334000051 334000051 334000051 334000051 334000051
GRID STOP IRIS L=35
6
334000050 334000050 334000050 334000050 334000050 334000050 334000050 334000050
GRID STOP IRIS L=70
7
511600040 511600040 511600040 511600040 511600041 511600041 511600041 511600041
ROLLER GROUP WULKOLAN WITH BEARINGS
8
315400090 315400090 315400090 315400090 315400100 315400100 315400100 315400100 THREAD PINS FOR THRUST BEARING ROLLER
9
303800400_50 303800260_50 303800260_50 303800260_50 303800360_50 303800360_50 303800360_50 303800360_50
THRUST BEARING ROLLER SUPPORT
10
352600030 352600030 352600030 352600030 352600030 352600030 352600030 352600030 MIXTURE BLOCK FIXING BRACKET
11 *
331700090 331700010 331700010 331700050 331700030 331700030 M253-93 331700070 MIXER COLUMN
12
361900031 361900041 361900051 361900061 361900071 361900081 361900091 361900100 MIXER BURR BOWL
13 *
356000180 356000180 356000180 356000180 356000180 356000180 356000180 356000180 WHITE PROFILE FOR MIXTURE STOP
14
362400511 362400510 362400511 362400512 362400513 362400514 362400517 362400760 MIXTURE BLOCK PROTECTION IRIS
15
511100190 511100050 511100050 511100050 511100060 511100060 511100060 511100060
BOWL THRUST BEARING SUPPORT GROUP
* WHEN ORDERING PLEASE SPECIFY MIXER COLOUR
WHEN ORDERING PARTS PLEASE SPECIFY REGISTRATION NUMBER
