_______________________________ DOUGH MIXER IRIS _______________________________
33
TAV. 05 Dough mixer IRIS 60-300 - Lower drive unit Rev.001 01-06-2012
Pos.
Mod. 60 Mod. 80 Mod. 100 130 Mod. Mod. 160 Mod. 200 Mod. 250 Mod. 300 Descrizione
1
315100050 315100020 315100020 315100010 315100010 315100010 315100010 315100010 MIXER BOWL-HOLDER SHAFT
2
422600005 422600007 422600007 422600010 422600010 422600010 422600010 422600010 OIL BLOCK
3
421025003 421005004 421005004 420812012 420812012 420812012 420812012 420812012
UPPER BEARING MIXER SPIRAL IRIS
4 *
303800310 303800220 303800220 303800160 303900040 303900040 303900220 303800160 SPIRAL BEARING SUPPORT
5
420812008 420812011 420812011 421005007 421005007 421005007 421005007 421005007 LOWER SPIRAL BEARING
6
321400051 321400051 321400051 321400020 321400020 321400020 321400020 321400020 PULLEY
7
423240066 423240074 423240074 423240089 423240090 423240090 423240092 423240093 TRAPEZOIDAL BELT
8
346600030
410112091
346600030
410112091
346600030
410112091
429000004 429000004 429000004 429000004 429000004 TONGUE/KEYER
9
315400050 315400050 315400050 315400050 315400050 315400050 315400050 315400050
TRANSMISSION CLUTCH PIN
10
420812007 420812007 420812007 420812007 420812007 420812007 420812007 420812007
RADIAL BEARING
11
315000070 315000070 315000070 315000070 315000070 315000070 315000070 315000070
ALBERO PER RINVIO VASCA
12
303800250 303800250 303800250 303800250 303800250 303800250 303800250 303800250
SUPPORTO RINVIO VASCA
13
321400090 321400090 321400090 321400210 321400210 321400210 321400210 321400210
PULLEY
14
POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27 POS.22 o POS. 27
15
415010142 415010142 415010142 415010142 415010142 415010142 415010142 415010142
TONGUE
16
423240085 423240088 423240088
423240091 *
423240091 423240091 423240091 423240091
TRAPEZOIDAL BELT
17
415010175 415010175 415010175 415010175 415010175 415010175 415010175 415010175
TONGUE
18
410112132 + 410123048 + 411061006 + 346600020 + 410156038 + 411080016
TWO HOLE WASHER FOR SHAFT
19 *
467221400 467221400 467221400 467231400 467241400 467241400 467241400 467241400
SPIRAL MOTOR
20
414501040 414501040 414501040 414501040 414501040 414501040 414501040 414501040
EXTERNAL STOP RING
21
321400060 321400060 321400060 321400520 321400200 321400200 321400200 321400200
PULLEY
22
309100020-53 309100020-53 309100020-53 309100020-53 309100020-53 309100020-53 309100020-53 309100020-53
THREADED BAR
23
411008010 411008010 411008010 411008010 411008010 411008010 411008010 411008010
PLAIN WASHER
24
482550003 482550003 482550003 482550003 482550003 482550003 482550003 482550003
6 LOBE WHEEL PASSING HOLE
25
346600030 346600030 346600030 346600030 346600030 346600030 346600030 346600030
TWO HOLE WASHER FOR SHAFT
26
321400110 321400110 321400110 321400150 321400150 321400150 321400150 321400150
PULLEY
27
309100030-53 309100030-53 309100030-53 309100030-53 309100030-53 309100030-53 309100030-53 309100030-53
THREADED BAR
28
303900070-53 303900070-53 303900070-53 303900070-53 303900070-53 303900070-53 303900070-53 303900070-53
BOWL MOTOR MOBILE SUPPORT
29
315400070 315400070 315400070 315400070 315400070 315400070 315400070 315400070
PIN MOTOR SUPPORT CLUTCH
30
482550003 482550003 482550003 482550003 482550003 482550003 482550003 482550003
6 LOBE WHEEL PASSING HOLE
* WHEN ORDERING PLEASE SPECIFY MIXER COLOUR
WHEN ORDERING PARTS PLEASE SPECIFY REGISTRATION NUMBER
