11
SYSTEM CONFIGURATIONS
MICRO4V2 - FULL MARINE/HOT ROD
SYSTEM WITH BTR
MICRO4V2 SIGNAL ENDPLATE
MICRO4V2 POWER/SPEAKER ENDPLATE
FRONT OUTPUT
SPEAKER HARNESS
REAR OUTPUT
SPEAKER HARNESS
SMARTPHONE
(BLUETOOTH)
DABTR
(BLUETOOTH RECEIVER)
SPECIAL BTR CABLE
(INCLUDED WITH BTR)
8 - 8 INCH HXM8
EXTREME HIGH OUTPUT
2-WAY SPEAKER
(wired 2 ohms ALL channels)
FRONT
REAR
