This sign is used in this booklet, wherever a
particular topic is safety sensitive or needs extra
care. Some of these items are specified in the
British Standard covering bicycles but many
others are Diamondback recommendations.
1. Chain wheel set
2. Front gear mechanism
3. Rear gear mechanism
4. Handlebar stem
5. Seat post
6. Multiple sprockets
7. Top tube
8. Seat tube
9. Down tube
10. Suspension fork
11. V-style brake
12. Disc brake
13. Rear suspension unit
14. Chain set axle bolt
90
0
12
14
3
6
12
5
4
10
13
1
2
7
4
11
14
1
3
6
5
11
8
9
2
FRAME NO.FRAME NO.
