Diaz Manu - Pairing the first remote; Alternative remote pairing method; Optional Features; Adjusting upper and lower limits

Somfy battery motor with transfo
www.diaz.be 2
V. 23-01
Pair the rst remote
2
ON
230V
OFF
230V
1 x
2 sec
2 x
OK
OK
1 x
2 sec release
Attention! Pair the
remote within 10 sec
after turning on the
power/operating P1.
Always choose the
right channel before
pairing or copying
a remote/channel.
Alternative method
2 x
2 sec
Turn on
power
Optional
Adjust upper and lower limit
1
OK
5
sec
3
sec
Go to upper
or lower
limit
OR
OR
STOP
STOP
OK
3
sec
PAIRED ADDITIONAL
PROG. A
PROG. A
PROG. B
PROG. B
Pair/remove additional remote/channel
2
1 x
1 x1 x
1 x
For the venetian blinds in alu and wood we always leave a gap of +/- 1 cm between the first slat and
the headrail. If the cords are under tension this will cause them to wear and break more rapidly.
Therefore we advise you not to change the upper position!
