Dickson TH8P3 User Manual

Dickson TH8P Manual V14 052418
3
1.
1.1.
1. To set the alarm, make sure unit is on and press and hold the Alarm
AlarmAlarm
Alarm button. The LED will blink red
rapidly for about five seconds, then the LED will turn solid green. Release the Alarm
AlarmAlarm
Alarm button and the
LED will turn solid red. At this point the display will show “On” or “Off”.
Pressing either the Adjust
AdjustAdjust
Adjust-
--
-Up
UpUp
Up or Adjust
AdjustAdjust
Adjust-
--
-Down
DownDown
Down buttons, located on the back of the unit next to the dip
switch, will toggle the alarm on or off.
2.
2.2.
2. Pressing PEN HOME will scroll to the next alarm options.
Pen 1 alarm minimum
Pen 1 alarm maximum
Pen 2 alarm minimum
Pen 2 alarm maximum
3.
3.3.
3. In order to set pen alarm minimums and maximums, pressing Adjust
AdjustAdjust
Adjust-
--
-Up
UpUp
Up will increase the alarm value,
and pressing Adjust
AdjustAdjust
Adjust-
--
-Dow
DowDow
Down
nn
n will decrease the alarm value. There is acceleration if the Adjust
AdjustAdjust
Adjust-
--
-Up
UpUp
Up button
is held down.
Repetitively pressing the Pen Home
Pen HomePen Home
Pen Home button will scroll through the five options until the A
AA
Alarm
larmlarm
larm button
is pressed to exit from alarm adjust. Each press of the Pen Home
Pen HomePen Home
Pen Home or Alarm
AlarmAlarm
Alarm button will store the new
settings. The unit will take one minute to exit Alarm Set Mode once the Alarm
AlarmAlarm
Alarm button is pressed.
4.
4.4.
4. If the alarm is triggered, the LED will show as solid red and the alarm will sound. Press the Alarm
AlarmAlarm
Alarm
button to silence the audible alarm.
Alarm Relays
Alarm RelaysAlarm Relays
Alarm Relays
The SPST 24V 500mA relay contacts are Normally open and will close on alarm conditions when the
alarms are enabled. Relay contacts are always functional when the alarm is enabled. The relay will close
only during minimum and maximum alarm conditions. Two pen models have 2 sets of relay contacts
which operate independently. Relays will not operate under battery only power conditions.
PENS
PENSPENS
PENS
The blue pen has a longer pen arm and records humidity or dew point (depending on your dip switch
selection, see pg. 4). The red pen has a shorter arm and records temperature. The pens are offset to allow
the red pen to glide under the blue pen. The blue pen indicates the correct time and the red pen
precedes it by 3/16 of an inch.
