Dielectric 2200ST SmartTech Modular Dehydrator - Page 32

26
Figure 7, Rear View
Water
Drain
Cabinet
Grounds
Low Pressure
Outlet 3/4" FPT
(46)
(not shown)
Power Entrance
Terminal Block
CO Alarm
Back up
Manual Operation Switch
(normally off)
(46)
(not shown)
CO Alarms
High Pressure
Outlet 3/4" FPT
ATS 300
Hookup
Segregated
Alarm
Hook up
