v
Figure No. Figure Description Page
1 Front view cover
2 Air/Water Flow Schematic 5
3 Front view 23
4 Side view, cabinet open 24
5 Electrical enclosure 25
7 Rear view 26
8 Inside View 27
9 Heat Exchanger/Fan Compartment 28
10 Heatless Dryer 29
11 Purge Solenoid Valves 29
Table Table Description Page
I Ta b le of Contents iv, v
II Table of Leading Particulars vi
Appendix Description Page
A Alarm Connection Wiring 30
A Alarm/ATS Interface Board 31
A Sensor Board 32
C Front Panel Display Features 34
C SmartTech Menu Block Diagram 35
C Setup Menu Block Diagram 36
D Wiring Electrical Schematic 37
E SmartTech Fusing and Circuit Protection 38
F SmartTech Alarms 39-40
G Power Termination and Grounding 41
H Glossary of Terms 42
INCLUDED WITH MODELS 22000ST / 33000ST
Part number Description Quantity
0040151001 Cabinet Air Filter 4
36565 Intake Filter Element (one installed) 2
46222 Water Filter Element (one installed) 2
41125 3/4" NPT Check Valve (refer to Par. 6.5) 1
47744 Back flow check valve 1
0005538032 3/4" NPT Hex Nipple 2
0016853013 3/8" Poly flo 1/4" NPT Fitting 1
MAINTENANCE KITS, PARTS AND ACCESSORIES
100495 12 month maint. kit (contains 2 each of the three types of filters listed above, required
each 12 mo. or 8000 hr.)
100496 24 month maint. kit (contains 2 purge solenoid valve overhaul kits, 1 water eject valve,
and above 12 month kit, required each 24 mo. or 16000 hr.)
46632P Automatic Transfer System is available to provide cycling between two with up to 8
dryers. When equipped with optional communications module, key personnel can
access any Central Office from a remote personal computer via modem, and de -
termine the overall status of the office.
105106 Floor Mounting Bracket Kit for securing Dehydrator Frame to the floor in Earthquake
Zoned Areas.
