TN 559 – Cleaning and replacing faders - All consoles Page 9
Appendix 1 – Fader table
Part Number
Section
Found In
Number Required
Note
681-00200
Input
SD12, Q2, Q3
24 in SD12 and Q225
38 in Q338
681-00199
Master
SD12, Q2
2 in SD12
1 in Q225
Longer cable version of 681-00200
686-00030
Input
SD9, SD10,
SD11
24 in SD9
36 in SD10
24 in SD10-24
12 in SD11
686-00031
Master
SD10
1
SC-SD7-FADERI
Input & Master Lower
SD7Q, SD5Q
SD7, SD5
36 in SD7/SD7Q
37 in SD5/SD5Q
100mm Fader standard cable
SC-SD7-FADERL
Master Lower
SD7
2
100mm Fader long cable
SC-SD7-FADERM
Master Upper
SD7
12
60mm Fader standard cable
SC-SD7-FADERML
Master Upper
SD7
2
60mm Fader long cable
POT000181
Input & Master
SD8
37
Solder tabs
PA16033
Input
SD8
3 sections
WHOLE CARD 12 Faders
PA16038
Master
SD8
1 section
Master fader and meter
681-00177
Input
S21, S31
20 in S21
30 in S31
681-00176
Master
S21, S31
1
Longer cable version of 681-00177
