Chapter 2: Expanded Pro Tools|HD Systems 11
Figure 2. Two 96 I/Os, 32-channel
HD Core
12-foot DigiLink cable
18-inch
Loop Sync cables
DigiLink
cable
Figure 3. Three 96 I/Os, 48-channel
HD Core
HD Accel
12-foot DigiLink cable
18-inch
Loop Sync cables
12-foot DigiLink cable
Loop Sync cables
TDM FlexCable
DigiLink
cable
or HD Process
