Digigram PCX924v2 - Switches; Connectors

D i g i g r a m
Switches
SW1 - Input impedance
(both levers must be set together)
Position Input impedance
OFF
> 10 kΩ
ON
600 Ω
SW2 – Inter-board synchronization
(both levers must be set together)
Position Status
OFF Slave
ON Master
Connectors
J1: Headphone
(3.5 mm TRS female jack)
Contact Signal
Sleeve Ground
Tip Left channel
Ring Right channel
J2 : Analog cable
J3: Digital cable
J4: CD Input
Position Signal
1 Left
2, 3 Ground
4 Right
J5: Inter-card synchronization connector
20
