Cam Guide
mini
9
Standard Knob
RFID Keypad
Shown in the locked position.
Vertical - Knob on the Bottom
Flat Washer
Cam-Stop
Star Washer
Phillips Screw M5
Flat Cam
(See below for other cam options)
Cam Options
Cam-Stop Options
Cylinder Length Options
Offset Cam Flat Cam Lifter Cam 90° Cam-Stop 180° Cam-Stop
22mm 16mm 30mm (Standard) 38mm
Example shows Confi guration 1a. See other confi guration options under the knob rotation section.
