Cam Guide
mini
3
ADA Handle
Keypad
Shown in the locked position.
RFID
Horizontal - ADA Handle on the Right
Phillips Screw M5
Flat Washer
Star Washer
Cam-Stop
Flat Cam
(See below for other cam options)
Cam Options
Cam-Stop Options
Cylinder Length Options
Offset Cam Flat Cam Lifter Cam 90° Cam-Stop 180° Cam-Stop
22mm 16mm 30mm (Standard) 38mm
Example shows Confi guration 2a. See other confi guration options under the ADA handle rotation section.
To Next Page
