DIGITAL FORECAST BRIDGE X TS - Standard and Performance Specifications; Physical Specifications; Digital Video Specifications; LCD Display Specifications

7
The standard and the performance
Physical
Size (W x H x D)
182.4 x 92.6 x 29 (mm)
weight
530 g
Supply Power
+ 12 VDC
Power Consumption
13 Watts (Maximum: 15Watts)
Operation temperature
0℃ ~ 70℃
humidity
0% ~ 95% RH, Non-condensing
Digital Video Specs
 HDMI v1.3 format Support
 Multi-rate SDI format Support
 SD format : 525/19.97(NTSC), 625/25(PAL), 480P, 576P
 HD format : 720P(24/25/30/50/59.94/60)
1080i(50/59.94/60)
1080p(24/25/30/sf24/50/59.94/60)
LCD Display Specs
 Size: 5.0 Inch
 Resolution : 800 x 480
 Pixel area : 0.135mm(W) x 0.135mm(H)
 Display area : 108mm(W) x 64.8(H)
182.4(W) x 92.6(L) x 29(H) mm
29 mm
92.6 mm
182.4 mm
