LCD Display
The UltraBlock USB incorporates an LCD display used to view a variety of
information. The information provided includes the make, model, serial number,
and capacity of the subject USB mass storage device. Other additional
information provided is intended to assist in troubleshooting situations.
The two buttons, Menu and Enter, on the top face of the UltraBlock USB allow
navigation among the various informational screens.
POWER ON
When the power switch is turned ON, the UltraBlock USB displays the following
screen.
While this screen is displayed, the UltraBlock USB performs an internal
diagnostic. During the diagnostic, the Host Detect, Write Block, Activity, and
Device Detect LEDs flash ON in sequence. At the end of the diagnostic, the
UltraBlock will illuminate the Write Block LED.
MAIN MENU
After the power-ON diagnostic is complete, the display defaults to the Status
Display. To view the Main Menu, press the Menu button once. Pressing the
Menu button repeatedly displays the following sequence of Main Menu
selections.
Status Display
Menu
The Menu button advances to the next Main Menu screen.
If an informational screen within a menu is currently dis-
played, then the Menu button returns the display to the
corresponding Main Menu screen.
Enter
The Enter button advances to the first informational
screen for that menu item. If an informational screen is
currently displayed, then the Enter button advances to the
next informational screen within the same Main Menu se-
lection.
Initializing
please wait...
Device Information Display
Mai n Menu
USB Devi ce I nf o
To Next Page
